Horizontal Beam Tack Welding Machine
The Horizontal Beam Tack Welding Machine from VATS Systematic Automation is designed for accurate assembly, alignment and tack welding of structural steel beams. It helps position the web and flange plates accurately before the final welding process, making it an important solution for H-beam and structural steel fabrication.
The machine is suitable for assembling and tack welding H-beams, T-beams and other compatible structural beam configurations. Its controlled clamping and positioning arrangement helps maintain beam geometry and supports consistent fabrication of structural components for construction, infrastructure, PEB and heavy fabrication applications.
Features of Horizontal Beam Tack Welding Machine
Accurate Beam Assembly
Designed to accurately position web and flange plates to form the required H-beam configuration before final welding.
Hydraulic Clamping
Hydraulic or application-specific clamping arrangements can help hold the beam components securely during alignment and tack welding.
Controlled Tack Welding
The system supports controlled tack welding to maintain the assembled beam geometry before subsequent welding operations.
Web & Flange Alignment
The machine helps maintain the relative position of web and flange plates for accurate H-beam assembly.
Adjustable Welding Parameters
Machine configurations can provide adjustable travel and welding parameters according to beam size, material and fabrication requirements.
Heavy Fabrication Applications
Suitable for structural steel, PEB, construction, infrastructure and heavy engineering fabrication.
How Horizontal Beam Tack Welding Works
Plate Loading
Prepared flange and web plates are positioned on the machine for the beam assembly process.
Beam Alignment
The web and flange plates are positioned and aligned according to the required beam dimensions.
Clamping
The components are held in position using the machine's clamping and positioning arrangement.
Tack Welding
Tack welds are applied to temporarily secure the web and flange assembly in the required configuration.
Beam Transfer
The assembled and tack-welded beam can then proceed to the next stage of the fabrication line.
Final Welding
The tack-welded beam can be transferred for subsequent final welding operations according to the production process.
Horizontal Beam Tack Welding Machine Specifications
| Parameter | Specification |
|---|---|
| Machine Type | Horizontal Beam Tack Welding Machine |
| Application | H-Beam Assembly & Tack Welding |
| Beam Type | H-Beam, T-Beam and Compatible Structural Beams |
| Welding Position | Horizontal |
| Welding Process | MIG / CO₂ Tack Welding or Other Compatible Process |
| Beam Length | 4000 – 15000 mm |
| Beam / Web Height | 200 – 1500 mm |
| Flange Width | 200 – 800 mm |
| Welding Speed | 300 – 1200 mm/min |
| Positioning Accuracy | Up to ±0.5 mm |
| Drive System | Motorized Drive with Inverter Control |
| Control System | PLC Based Control with Touchscreen Interface |
| Clamping System | Hydraulic / Pneumatic, According to Configuration |
| Power Supply | AC 380V ±10%, 50/60Hz, 3 Phase |
| Cooling System | Air / Water Cooled According to Welding Source |
| Machine Structure | Heavy-Duty Industrial Structure |
| Machine Configuration | Customizable According to Beam Fabrication Requirements |
Beam Types Suitable for Tack Welding
H-Beams
I-Beams
T-Beams
Structural Steel Beams
PEB Structural Components
Heavy Fabricated Beams
Applications of Horizontal Beam Tack Welding Machine
PEB Steel Structure Fabrication
Structural Steel Fabrication
Building Construction
Bridge Construction
Industrial Buildings
Heavy Engineering
Crane Beam Fabrication
Railway Structures
Industrial Infrastructure
Warehouse Structures
Steel Fabrication Units
General Structural Fabrication
Advantages of Horizontal Beam Tack Welding
Accurate Beam Alignment
Controlled positioning helps maintain the required relationship between web and flange plates during beam assembly.
Reduced Manual Handling
Mechanical positioning and clamping can reduce repetitive manual alignment work during beam assembly.
Consistent Tack Welding
Controlled welding parameters support consistent tack welding across repeated beam fabrication operations.
Improved Beam Geometry
Accurate web and flange positioning helps maintain beam geometry before the final welding stage.
Production Efficiency
A dedicated beam assembly and tack welding system can streamline the pre-welding stage of structural fabrication.
Suitable for Heavy Fabrication
Designed for structural steel, PEB and other heavy fabrication environments requiring reliable beam assembly.
From Plate Assembly to Final Beam Welding
Plate Preparation
Flange and web plates are prepared according to the required beam dimensions.
Assembly & Alignment
The plates are positioned and aligned to form the required beam cross-section.
Tack Welding
Tack welds temporarily secure the assembled beam before the main welding operation.
Main Welding
The tack-welded beam moves to the next welding stage, such as a suitable SAW or other final welding system.
Why Choose VATS Systematic Automation?
VATS Systematic Automation LLP provides welding, CNC cutting and industrial automation solutions for modern manufacturing and structural fabrication requirements. Our product portfolio includes CNC plasma cutting machines, fiber laser cutting machines, welding machines, beam fabrication equipment, bending machines, drilling machines, CNC controllers, plasma components and industrial consumables.
We focus on understanding customer application, beam dimensions and production requirements before recommending a suitable machine configuration. Our team also provides technical guidance, installation assistance and after-sales support for industrial machinery.
Horizontal Beam Tack Welding Machine Supplier
VATS Systematic Automation LLP is a manufacturer, supplier and trader of welding and fabrication machines, CNC plasma cutting machines, fiber laser systems, bending machines, drilling machines, CNC controllers, plasma consumables and industrial automation solutions.
If you are looking for a Horizontal Beam Tack Welding Machine, our team can help you identify a suitable configuration based on beam height, flange width, beam length, plate thickness, welding process and production requirements.
Looking for a Horizontal Beam Tack Welding Machine?
Share your H-beam fabrication requirements with VATS Systematic Automation and get guidance on a suitable beam assembly and tack welding solution for your production.
